CPU |
32bit |
Reader |
Optical Fingerprint Reader, Dual Fingerprint Reader (Optical) |
Proximity Card |
EM, MIFARE Card (Optional) |
Display |
2.8" TFT True Color LCD |
LED Indicator |
2 Colors with Red & Green |
Interface |
Duress Alarm Output (COM;NO;NC), Door Bell Button Input (PUSH:GND) Door Lock On
/ Off Input, Door Bell Output, Anti Pass Black Port (TXD, TXD, GND) |
USB Disk |
Yes (Optional) |
Additional Feature |
Reset Buttom |
Notification |
Voice |
Real Time Clock |
Yes |
Power |
Power (DC 9V / 12V) |
Temperature |
-10 C±600C |
Humidity |
20%-80% |
Operation |
One-Way, Two-Way, Multi Door / Network |
Registration Capacity |
Advanced:2000 FP / 2000 Card Passwords |
Authentication Methods |
Fingerprint, EM Card, Password, Dual Fingrprint, Group Combination Autentication |
Access Control |
Able to control single door access through wiegand, 50 time periods, time
setting authentication, Anti Pass Back, sending attendance records by records by
real time to server to PC support Dual Fingerprint or Group Combination
Authentication |
Alarm |
Force Removal Alarm, Duress Alarm, Force Door Open Alarm, Overtime Alarm |
Memory Capacity |
Normal:100,000FP |
Auto Self-check |
Yes |
FAR/FRR |
0.00001% 0.1% |
FP Verification Speed |
≤1.0s (with 2000 FP registration) |
FIP Verification Angle |
00-3600 |
Smart FP Update |
Yes |
FP Verification Mode |
1:N, 1:1 Dual Fingerprint or Group Combination Authentication |
