Biometric | Fingerprint | |
Main | ||
IP Rating | - | |
RF Option | 125KHz EM, 125KHZ HID Prox, 13.56MHz Mifare/DesFire | |
Multi-Controller | Yes | |
Capacity | Max. User (1:1) | 200,000 |
Max. User (1:N) | 10,000 | |
Max. Template (1:1) | 400,000 | |
Max. Template (1:N) | 20,000 | |
Max. Text Log | 1,000,000 | |
Max. Image Log | - | |
Interface | WiFi | Optional |
TCP/IP | Yes | |
RS-485 | 1ch Host or Slave (Selectable) | |
RS-232 | Yes | |
Wiegand | 1ch In 1ch Out |
|
Input | 2 Inputs | |
Relay | 1 Relay | |
USB | Host and Slave | |
SD Card Slot | - | |
Hardware | CPU | 200MHz RISC + 533MHz DSP |
Memory | 34MB RAM + 1GB Flash | |
LCD | 2.5" Color | |
LED Indicator | Blue | |
Sound | 16bit Hi-Fi | |
Operating Temp. | -20° to 50°C | |
Tamper | Yes | |
Power | 12VDC | |
PoE | - | |
Dimensions | 135 x 128 x 50 (WxHxD mm) | |
Certificates | CE, FCC, MSIP(KCC), RoHS | |
Compatibility | BioStar 1.x | Yes |
BioStar 2 | - |
