Max. User |
300/700 |
Face Template Capacity |
300/700 |
Fingerprint Template Capacity |
3,000 |
Log Capacity |
200,000 |
Password Capacity |
1,000 |
Card Capacity (Optional) |
1,000 |
RF Card Options |
125kHz EM / 13.56MHz Mifare |
Authentication Modes |
Face / Fingerprint / Password / Card / Face+Password /
Fingerprint+Password / Card+Password |
Verification Time |
< 1 second [1:N] CPU Samsung 2440, 400MHz |
Image Sensor |
Special stereo dual sensor, detection range up to 80cm |
LCD Display |
2.8" TFT color screen 320x240 pixel |
Interface |
TCP/IP, USB host, USB slave, Wiegand 26-bit output, 1x Relay |
Voice Instruction |
16-bit Hi-Fi voice & Sound Indication |
Language |
English |
Power Source |
12VDC / 2A |
External Backup Battery |
Optional |
Operating Temperature |
0ºC - 40ºC |
Operating Humidity |
20% - 80%RH |
Dimensions (mm) |
199 x 118 x 97 mm |
Weight (kg) |
0.55 g |
